Introducing the Kodair Wind range of small wind turbines, our current offerings are the KW20 and the KW30, these turbines are built on the same platform and consist of the following features:

  • Variable pitch system – For capturing the wind efficiently at all wind speeds.
  • Motorised Yaw system – For aligning the turbine in the direction of the wind.
  • Extra fail safe system – To move the blade pitch to the parking position if the primary pitch system has a fault.
  • Automatic Lubrication systems – To lengthen the time periods between service intervals.
  • Ladder access system – To enable service and maintenance to be performed without the need to drop the turbine to the ground.
  • Tower Tilt System – To allow easy installation or removal of the nacelle from the tower.
  • Web based remote monitoring system
  • Direct Drive Permanent Magnet Radial Alternator – No Gearbox

Our turbines are currently undergoing certification testing for the US market, They will be certified by SWCC and we are under guidance from Joseph Spossey of RE Innovations LLC. Our preliminary power curves after several weeks of power performance testing are shown below. Please note that these are preliminary curves and subject to change upon completion of power performance testing

KW20

ClassII
Rated Power 20KW
Rotor Diameter13.05 Meters
Swept Area133.75 Meters
Cut in windspeed2.5 Meters Per Second
Cut out windspeed25 Meters Per Second
Rated windspeed10 Meters Per Second
Survival windspeed52.5 Meters Per Second
Rotations Per Minute73
Weight1800 KG
Hub Height20 Meters
Click Here
Click Here
Click Here
Previous slide
Next slide

KW30

ClassII
Rated Power 30KW
Rotor Diameter14.10 Meters
Swept Area156.14 Meters
Cut in windspeed2.5 Meters Per Second
Cut out windspeed25 Meters Per Second
Rated windspeed10 Meters Per Second
Survival windspeed52.5 Meters Per Second
Rotations Per Minute73
Weight1835 KG
Hub Height24 Meters
Click Here
Click Here
Click Here
Previous slide
Next slide

Subscribe to our mailing list to be the first to know about the kodair turbine!!
